Equipment Details

Side Discharge

Truck Mount Fertilizer Tender

Each Side Discharge Fertilizer Tender is built with the highest of quality standards. Brehmer test all steel as it comes through the plant, so we can guarantee that you’ll receive a 304 stainless side discharge fertilizer tender.

FEATURES:

  • 4 Bin on 16 Ft., 3 Bin on 18 Ft, 5 Bin on 20 Ft , and 6 Bin on 24 Ft
  • 304 Stainless Steel Bins and Auger Flighting Systems
  • Self-locking Hydraulic Discharge Auger
  • Max Unloading Capacity of 3500-4000 LBS/MIN
  • Low Center of Gravity Box (Unique Bin Design)
  • EZ Slide Gates System
  • Stainless Steel Motor Coupling Shafts
  • Individual Hopper Ladders
  • Reinforced Corner Gussets
  • Grease Banks
  • Unique Bearing Design
  • 2″ Clean-outs
  • Filled-In Tarp Bow System

OPTIONS:

  • Split Bins
  • 6″ Taller Sides

Brehmer Dry Fertilizer Tenders frame options:

   Stainless Steel

   Tender Gray

Click the tabs below to expand and view measurements for the truck mount side discharge fertilizer tender

16' Tender Measurements
  • Travel Height – 7’2″
  • Auger Length – 16’7″
  • Discharge Height: MIN – 7’1″
  • Discharge Height: MAX – 14’2″
  • Auger Reach: SIDE – 13’4″
  • Standard Cubic Feet – 569
  • 6″ Taller Cubic Feet – 633

Discharge height is measured from the top of the existing truck or trailer frame.

18' Tender Measurements
  • Travel Height – 7’2″
  • Auger Length – 16’7″
  • Discharge Height: MIN – 7’1″
  • Discharge Height: MAX – 14’2″
  • Auger Reach: SIDE – 13’4″
  • Standard Cubic Feet – 663
  • 6″ Taller Cubic Feet – 735

Discharge height is measured from the top of the existing truck or trailer frame.

20' Tender Measurements
  • Travel Height – 7’2″
  • Auger Length – 16’7″
  • Discharge Height: MIN – 7’1″
  • Discharge Height: MAX – 14’2″
  • Auger Reach: SIDE – 13’4″
  • Standard Cubic Feet – 711
  • 6″ Taller Cubic Feet – 791

Discharge height is measured from the top of the existing truck or trailer frame.
